MODEL
HiSpeed CT-e Dual
X-RAY TUBE
X-RAY TUBE ANODE
Heat storage, hu (X-ray tube anode) 2,0,000
Heat dissipation rate, hu/min (X-RAY TUBE) 500000
Tube cooling (X-ray tube anode) Oil/air
Tube focal spot, mm (X-ray tube anode) 0.7 x 0.6
POWER NEEDED 460/480 VAC nominal, 50/60 Hz, 3-phase delta or Wye
Type (CONFIGURATION) Dual slice
# of slices (X-ray tube anode) 2
DICOM 3.0 COMPATIBLE (POWER NEEDED, VAC) Yes
DISPLAY
MONITOR 21"
Matrixes, pixels (DISPLAY) 1280 x 1024
Range of ct numbers (DISPLAY) -32,767 to +32,767
Image enlarging scale (DISPLAY) Up to 8x
Max # slices displayed simultaneously (DISPLAY) 16
TABLE FEATURES
Range of movement
Vertical, cm (Range of movement) 40-90
Longitudinal, cm (Range of movement) 120
Scanning range,cm (Range of movement) 120
Max. patient weight, (precision), kg (Range of movement) 180 (not specified)
FLOOR SPACE NEEDED
Size, m2 (FLOOR SPACE NEEDED) 13
GENERATOR
Output, kw (X-RAY GENERATORS) 24
Kvp range (GENERATOR) 120
Ma range (IMAGING SYSTEM) 10-00
IMAGE PROCESSING (MAXIMUM DISPLAY)
Cpu (NETWORK/DATABASE) Open architecture/ LINUX
Scan fovs, cm (IMAGE PROCESSING) 18,25,35, 43
Image reconstruction matrixes (IMAGE PROCESSING) 256 x 256, 320 x 320, 512 x 512
Reconstruction time
Per slice, sec (Reconstruction time) 1.8
For localization scan, sec (Reconstruction time) Real time
HELICAL SCANNING (DISPLAY) Yes
Max scan time, sec (DISPLAY) 60optional 90
Max scan volume, cm (DISPLAY) 120
Spatial resolution, lp/cm (DISPLAY) Same as axial
Pitch (DISPLAY) 0.75:1 to 1.5:1 (2-slice mode)
Reconstruction time per image, sec (DISPLAY) 1.8
Image storage
Hd capacity, gb (IMAGE STORAGE) 80
No. online images (IMAGE STORAGE) 40000
Archive (IMAGE STORAGE) 2.3 GB MOD, DICOM 3.0
PERFORMANCE
Minimum interscan time, sec (PERFORMANCE) 1
Dynamic scan pace (PERFORMANCE) 60 scans/min
High-contrast spatial resolution 0% mtf, lp/cm (PERFORMANCE) 13.3
50% mtf, lp/cm (PERFORMANCE) 9.5
Low-contrast resolution, mm at % at
